CRI Dora 100 Pump (1 H.P.)

• 🌟 CRI Dora 100 Pump – 1 HP Self-Priming Monoblock Pump

  The CRI Dora 100 Pump is a high-performance self-priming monoblock pump designed for domestic, agricultural, and industrial applications. With its robust construction, excellent hydraulic efficiency, and low noise operation, it ensures reliable and long-lasting performance.

  ---

  💡 Key Features & Benefits

  ✅ High Efficiency Motor:

  • AC induction two-pole motor for consistent performance.

  • Low watt-loss silicon laminations reduce energy consumption.

  ✅ Thermal Overload Protection:

  • Built-in imported thermal overload protector (TOP).

  • Protects the pump from overheating and voltage fluctuations.

  ✅ Wide Voltage Range:

  • Operates effectively between 200 to 240V (single-phase).

  • Ensures smooth performance even during voltage variations.

  ✅ Durable Construction:

  • Pump casing & mounting: Made of cast iron for durability.

  • Motor body: Made of extruded aluminum, providing excellent heat dissipation.

  • Impeller: Brass impeller for corrosion resistance and longevity.

  ✅ Smooth & Quiet Operation:

  • Double-sealed ball bearings for noise-free functioning.

  • Low-temperature rise for increased motor lifespan.

  ✅ Compact & Sturdy Design:

  • Powder-coated multi-color stator body enhances durability.

  • Compact size makes it easy to install and maintain.

  ✅ Warranty:

  • 1 year warranty against manufacturing defects.

  ---

  💧 Major Applications

  • 🏡 Domestic Water Supply:

    • Ideal for bungalows, apartments, and farmhouses.

  • 🛠️ Agricultural Use:

    • Suitable for small-scale irrigation and water transfer.

  • 🏢 Commercial Buildings:

    • Reliable for water circulation in small industries.

  • 🌿 Gardening & Sprinkler Systems:

    • Perfect for watering gardens and lawns.

  ---

  🔧 Technical Specifications

  Specification	Details
  Brand	CRI Pumps
  Model	Dora 100
  Power Rating	0.75 kW / 1.0 HP
  Head Range	6 – 35 meters
  Flow Capacity	3000 – 1100 LPH
  Voltage Range	200 – 240V (Single Phase)
  Pump Casing & Mounting	Cast Iron
  Motor Body	Extruded Aluminum
  Impeller	Brass
  Pump Shaft	Carbon Steel / SS410
  Mechanical Seal	Carbon Ceramic
  Warranty	1 Year Against Manufacturing Defects

  ---

  🌟 Why Choose the CRI Dora 100 Pump?

  • ✅ High Performance:

    • Excellent hydraulic efficiency and suction lift.

  • ⚡ Reliable & Durable:

    • Overload protection ensures safety and longevity.

  • 🔧 Low Maintenance:

    • Noise-free operation with minimal servicing.

  • 🇮🇳 Made in India:

    • Trusted CRI brand known for quality and reliability.

  ---

  ✨ Invest in the CRI Dora 100 Pump for reliable, efficient, and long-lasting water pumping solutions! 🌊



product code : SIE2025033185
