Description
The Lubi LCR series are non-self-priming, vertical multistage centrifugal pumps.
The vertical in-line design enables the pump to be installed in a horizontal plane single system where the suction and discharge connections are in the same horizontal plane (in-line) and have the same pipe sizes. This design provides a more compact pump design saving space and easy pipe work.
The pump consists of a base and a pump head. The chamber stack and the outer sleeve are secured between the pump head and the base by means of tiebolts. All pumps are equipped with a maintenance-free mechanical shaft seal.
Specifications
| Brand: | LUBI Pumps |
| Motor Power (KW/HP): | 1.1 KW/1.5 HP |
| Stage: | 2-11 |
| Type: | Multistage vertical high pressure pump |
| Weight: | 22 kgs |
| Speed (n): | 2900 rpm |
| Phase: | Three Phase |
The Lubi LCR series are non-self-priming, vertical multistage centrifugal pumps.
The vertical in-line design enables the pump to be installed in a horizontal plane single system where the suction and discharge connections are in the same horizontal plane (in-line) and have the same pipe sizes. This design provides a more compact pump design saving space and easy pipe work.
The pump consists of a base and a pump head. The chamber stack and the outer sleeve are secured between the pump head and the base by means of tiebolts. All pumps are equipped with a maintenance-free mechanical shaft seal.
Specifications
| Brand: | LUBI Pumps |
| Motor Power (KW/HP): | 1.1 KW/1.5 HP |
| Stage: | 2-11 |
| Type: | Multistage vertical high pressure pump |
| Weight: | 22 kgs |
| Speed (n): | 2900 rpm |
| Phase: | Three Phase |
