DOW FilmTec™ SW30HRLE-440i RO Membrane
🔥 6 customers viewed this today
Original price was: ₹ 50000.₹ 46000Current price is: ₹ 46000.
• Delivery will be made after the payment is credited to our bank account.
• Transportation charges are extra and will be charged on an actual basis.
The DOW FilmTec™ SW30HRLE-440i RO Membrane is a high-performance seawater reverse osmosis element. We designed it for seawater desalination. Additionally, it supports high-salinity water treatment applications.
Product Overview
The DOW FilmTec™ SW30HRLE-440i RO Membrane is a high-performance seawater reverse osmosis membrane element designed for seawater desalination and high-salinity water treatment applications. It combines high water productivity with excellent salt and boron rejection for reliable permeate quality.
With a 440 ft² (41 m²) active membrane area, 8,000 GPD (30.2 m³/day) permeate flow, and 99.80% stabilized salt rejection, the SW30HRLE-440i is designed for municipal and industrial seawater desalination systems. It features a 28-mil feed spacer and iLEC™ interlocking end caps for efficient installation, maintenance, and reliable operation.
Key Features
- High Salt Rejection: Up to 99.80% stabilized salt rejection.
- High Productivity: 8,000 GPD permeate flow under specified test conditions.
- High Boron Rejection: 92% stabilized boron rejection.
- Large Active Area: 440 ft² (41 m²) helps maximize system productivity.
- Low Maintenance: iLEC™ interlocking end caps help reduce O-ring leak risks and simplify installation.
- Reliable Performance: Designed for stable, long-term operation.
- Seawater Application: Suitable for medium- and high-salinity feedwater.
Technical Specifications
| Parameter | Specification |
| Brand | DOW / DuPont FilmTec™ |
| Model | SW30HRLE-440i |
| Product Type | Seawater Reverse Osmosis Membrane |
| Membrane Type | Polyamide Thin-Film Composite |
| Element Size | 8 Inch |
| Active Membrane Area | 440 ft² (41 m²) |
| Feed Spacer Thickness | 28 mil |
| Permeate Flow Rate | 8,000 GPD (30.2 m³/day) |
| Stabilized Salt Rejection | 99.80% |
| Minimum Salt Rejection | 99.65% |
| Stabilized Boron Rejection | 92% |
| Maximum Operating Temperature | 45°C (113°F) |
| Maximum Operating Pressure | 1,200 psi (83 bar) |
| Maximum Pressure Drop / Element | 15 psi (1.0 bar) |
| Continuous Operating pH | 2–11 |
| Short-Term Cleaning pH | 1–13 |
| Maximum Feed SDI | SDI 5 |
| Free Chlorine Tolerance | < 0.1 ppm |
| End Cap Technology | iLEC™ Interlocking End Caps |
Applications
- Seawater desalination plants
- Municipal desalination systems
- Industrial seawater RO plants
- High-salinity water treatment
- Drinking water production from seawater
- Industrial process water treatment
- Large-scale seawater reverse osmosis systems
Benefits
- High Salt Rejection – Up to 99.80%
- High Productivity – Up to 8,000 GPD
- High Boron Rejection – 92%
- Large Active Area – 440 ft² (41 m²)
- Energy-Efficient Operation
- Reliable Long-Term Performance
- Ideal for Seawater Desalination
- iLEC™ End Cap Design – Easy installation and maintenance
